DCS50FT-1 40–50kg Semi-Automatic Powder Bagging Scale
DCS50FT-1 40–50kg Semi-Automatic Powder Bagging Scale
Get a Quote for This Machine
Typical response within one business day · Machine recommendation from our engineers
A semi-automatic powder bagging scale for 40–50 kg (88–110 lb) bags at 100–180 bags per hour. A double twisted-cage feeder and a three-sensor scale dose the powder; the operator places the bag and the machine feeds, fills and releases it. The DCS50FT-1 comes with a manual lifting conveyor; the DCS50FT-2 is the same scale without a conveyor.
40–50 kg88–110 lb per bag
100–180bags per hour
X(0.5)accuracy class, 10 g graduation
2 versionswith or without conveyor
Speed depends on the powder and on operator pace.
Is the DCS50FT-1 the right fit?
Good fit
- Plants bagging powder in 40–50 kg bags at moderate output
- Lines that already have a bag conveyor (choose the DCS50FT-2)
- Products that clump now and then and need easy manual clean-out
Look at another model if
- You pack flour into open-mouth bags: see the DCS-50FT2-B
- You pack rice husk or other light powder: see the DCS-50ZF2
- Your product is a free-flowing granule: see the DCS-50FE2-B
How one cycle works
-
Bag clamping
The operator places the bag and closes the clamp by hand switch or foot pedal. -
Feeding
The double twisted-cage feeder doses the powder. -
Weighing
Three load cells support the hopper so uneven filling does not distort the reading. -
Release
The bag is discharged; on the DCS50FT-1 it goes onto the lifting conveyor.
Technical specifications
| Item | Metric | US units |
|---|---|---|
| Bag weight | 40–50 kg | 88–110 lb |
| Accuracy class | X(0.5) | |
| Graduation | 10 g | about 0.35 oz |
| Output | 100–180 bags/h | 100–180 bags/h |
| Conveyor | DCS50FT-1: powder-scale manual lifting conveyor; DCS50FT-2: none | |
| Power | DCS50FT-1: 3.7 kW; DCS50FT-2: 2.7 kW | |
| Power supply | AC 220 V ±5% or AC 380 V ±5%, 50 Hz | |
| Compressed air | 17 L/min at 0.4–0.5 MPa | about 0.6 CFM at 58–73 psi |
| Footprint, DCS50FT-1 | 2,808 × 1,342 × 3,076 mm | about 9.2 × 4.4 × 10.1 ft |
| Footprint, DCS50FT-2 | 1,030 × 1,336 × 2,771 mm | about 3.4 × 4.4 × 9.1 ft |
| Operating conditions | 0–40 °C, ≤90% RH | 32–104 °F |
Safety and build
- Out-of-tolerance alarm
- Manual control of discharge and bag-loosening for cleaning out clumps
- Three-sensor support against signal distortion from uneven material
Add to the line
The scale can be connected to conveyors, a check weigher, a metal detector and a palletizer robot. We supply the full line and its layout.
Get a quote for your plant
To size the machine and give you a price, we need five things:
- Product (for example wheat flour, feed premix, starch)
- Bag weight and bag type
- Target bags per hour or tons per shift
- Power supply (voltage and Hz)
- Equipment before and after the bagger
